Monitor
Screen Size 6.2" Wide VGA
Number of Pixels 1,152,000 (800 x 480 x RGB)
Colour System PAL/NTSC
Touch Panel Yes
Dimmer Yes
Multilingual Display Yes (English / Arabic)
Media Playback
MP3/WMA Compatible with ID3 Tag/WMA Tag CD / DVD / USB
MPEG 1/2 Compatible CD / DVD / USB
JPEG File Playback CD / DVD / USB
CD Player
CD-R/RW Compatible Yes
CD Text Yes
Random/Repeat Play Yes
DVD Player
DVD-R/-RW, +R/+RW Compatible Yes
Video Format NTSC/PAL
Dolby Digital 2ch
Video CD Playback Yes
Frequency Response 96kHz Sampling: 20 - 20,000Hz, 48kHz Sampling: 20 - 20,000Hz, 44.1kHz Sampling: 20 - 20,000Hz
Dynamic Range 90dB
Signal-to-Noise Ratio 90dB
Wow & Flutter Below measurable limit
iPod/iPhone Control
iPod/iPhone Music Playback Yes (USB)
Random/Repeat Play Yes (USB)
Text Yes (USB)
Battery Charge Yes (USB: 1A Max.)
USB
USB Port x1 (Full Speed)
Position Front
Random/Repeat Play Yes
USB Power Supply Yes (1A)
USB Mass Storage Class (for music/video/picture files) Yes
Radio Tuner
Radio Data System Yes
Digital Processing Tuner Yes
Preset Stations 30 (6ch x 5band)
Automatic Presetting (Strong Station Sequential Memory) Yes
FM
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity 11.2dBf (1.0uV/75 ohms)
Quieting Sensitivity (46dB) 16.4dBf (1.8uV /75 ohms)
Stereo Separation 40dB
AM
Frequency Range 531 - 1,611kHz
Sensitivity 36uV
Audio
Maximum Power Output (Front & Rear) 50W x 4
Full Bandwidth Power (Front & Rear) 20W x 4
EQ
3-Band Parametric EQ Yes
Preset EQ Yes (6-Preset)
Bass Boost (Hyper Bass System) Yes
High-Pass Filter/Low-Pass Filter -/Yes
Inputs and Outputs
Pre-output Level/Impedance 2.0V / 10k ohms
External video input level (RCA/mini jack) 1.0Vp-p / 75 ohms
Video Output level (RCA jacks) 1.0Vp-p / 75 ohms
AV Input Terminals (Video + L/R) Yes
Rear view camera Input Yes
Line Output Terminals (pair) 3 Pairs (Front + Rear + Subwoofer)
Subwoofer Output with Level/Frequency Control Yes
Composite Video Output Yes
General
Wireless Remote Control Yes
Rear-View Camera Ready Yes
ISO Connector Yes
Dimensions (W x H x D)
Installation Size 178 x 100.8 x 160 (mm)
Weight 1.9 kg
